The Barco Formatter Board for DP2K-32B is a critical component in Barco’s high-performance DLP cinema projectors. Engineered for triple-DMD architecture, this board handles the essential task of receiving processed image signals from the ICP (Image Control Processor) and distributing them to the three DMD chips that create the projected image.
Designed specifically for the Barco DP2K-32B, one of Barco’s flagship 2K digital cinema projectors, the formatter board ensures precise timing, high-speed data integrity, and synchronization between RGB channels. It supports up to 2K DCI resolution (2048 x 1080) and is essential for maintaining image fidelity in professional cinema applications.
This unit is refurbished, fully tested, and offered with optional matching signal and power cables for the light engine, making it a direct replacement for failed or aging formatter boards in existing projection systems.
🔧 Installation Note: As with all internal projector components, the formatter board must be installed by a qualified technician, observing strict ESD handling and matching firmware versions with the ICP board.
---
Would you like me to create SEO-optimized titles, product tags, or multi-language versions as well?
| **Category** | **Details**
| ------------------------ | ----------------------------------------------------------------------------
| **Part Name** | Formatter Board for Barco DP2K-32B
| **Manufacturer** | Barco (OEM)
| **Compatible Projector** | Barco DP2K-32B, DP2K series DLP projectors with 3-chip DMD engine
| **Board Function** | High-speed video processing and control of 3x DMD chips
| **Resolution Support** | 2K DCI (2048 x 1080), up to 12-bit color depth
| **Supported Inputs** | Receives digital video via ICP (Image Control Processor)
| **DMD Interface** | Drives 3x DMDs via dedicated LVDS / high-speed signal paths
| **Voltage Requirements** | Supplied by projector power system – 3.3V, 5V, and 12V DC
| **Board Connectors** | Multiple ribbon and pin connectors for: DMD, ICP board, and PSU
| **Signal Interfaces** | Internal proprietary digital signaling between formatter and ICP
| **Cooling Method** | Passive – cooled via projector chassis airflow
| **Firmware** | Firmware-matched per projector type – should match ICP & light engine
| **Part Condition** | Refurbished, tested, ESD-protected
| **Included Cables** | Comes with matching light engine signal and power cables (if requested)
| **Installation Notes** | Must be installed by qualified personnel using ESD precautions
| **Quality Control** | Functional testing on all DMD channels, thermal checks, and signal integrity
